Support for LS2 SPECTRUM
Code: C1676.02
Helmet Mount
Upgrade
Usage video
FAQ
Manuals, Quick Guides and Software
Packaging Disposal
Register Product
Upgrade
Here you will find the video and the software to upgrade your device
Download the software to upgrade your device for Windows computers
BTUpdater_Windows_108_3012
82.3 MB
FAQ
Here you will find the answers to the most frequently asked questions about your device
1. Which LS2 helmets are compatible with my SPECTRUM?
The list of compatible helmets is provided by LS2.
2. How can I pair my SPECTRUM with a phone, TFT, or GPS?
Pairing your SPECTRUM with a phone, TFT multimedia display, or GPS navigator is very
simple. Follow these easy steps to get started.
With the device turned off, press and hold the central button for seven seconds. The LED will
flash blue and red, indicating it is ready for pairing.
On your phone, multimedia display, or GPS, go to Bluetooth settings and look for
SPECTRUM in the list of available devices.
Click to confirm and, if prompted, enter the PIN code 0000. The LED on your SPECTRUM
will flash four times to confirm successful pairing.
Your device is now connected and ready to use.
If your motorcycle has a TFT multimedia display, pair it directly with the intercom and, for
optimal connection, pair your smartphone only to the display.
You can pair up to three intercoms and one additional device, such as a phone, motorcycle
TFT display, or GPS.
A total of up to three intercom devices (LS2 and/or other brands) can be paired.
Pairing another device to the same button will overwrite the previous one.
SPECTRUM is compatible with intercoms from all brands. However, some models may
require a special procedure using the Universal Intercom function.
Midland, LS2, CARDO, and some SENA models pair easily. Select one of the three buttons
on your SPECTRUM for pairing the other intercom. With the device turned on, press and
hold the selected button for seven seconds until the LEDs start flashing blue and red. Then,
on the other device, start the intercom pairing process following the manufacturer’s
instructions. SPECTRUM will confirm the pairing with a flash.
For intercoms from other brands, repeat the same procedure on your SPECTRUM, but on the
other intercom, start the phone pairing procedure following the instructions in its manual.
Updating your device is quick and easy.
Download the BTUpdater software from the UPDATE section on the official website install it.
Connect the device to your PC using the charging cable, and the software will guide you
through the process.
BTUpdater is currently only compatible with Windows PCs and is not available for Mac
devices
To start the intercom communication from your SPECTRUM, simply press once the button
you used to pair the other device.
To increase the volume, press and hold the front button (Volume +).
To decrease the volume, press and hold the rear button (Volume -).
You can adjust the volume only while listening to an audio source, such as the intercom or
music.
If the audio seems low or unbalanced, the helmet speakers may not be positioned correctly
Check the speaker position by removing the helmet and ensuring that the speakers are
properly aligned with your ears.
Test the sound by removing the speakers from the helmet and placing them directly on your
ears. If the sound improves, the issue is due to incorrect positioning inside the helmet.
Changing the language on your SPECTRUM is simple. Follow these steps.
With the device turned on, press and hold the front button (Volume +) for more than nine
seconds.
Keep holding it until you hear the battery status in your desired language.
Release the button when you hear the language you want to select.
Simply press the central button twice.
To answer or end a call, press any button on SPECTRUM.
To reject an incoming call, press and hold any button for three seconds.
SPECTRUM also features Auto Answer. If this function is enabled, the intercom will
automatically answer the call after eight seconds. To activate or deactivate it, with the device
turned off, press and hold the Central and Back (Volume -) buttons for more than nine
seconds
Open your preferred music app on your phone.
Press and hold the central button for two seconds to start or pause the music.
While listening to a track, you can skip to the next song by double-pressing the forward
button (Volume +) or return to the previous song by double-pressing the back button (Volume
-).
It is not possible to listen to music while talking via intercom. The music will automatically
resume once the intercom is closed.
Music Share allows you to share the music you are listening to with your passenger
Open your preferred music app on your phone.
Start the intercom connection with your passenger.
Press and hold the central button for two seconds. You will hear a confirmation tone
indicating that Music Share has been activated.
The range specified in the product description was tested under optimal conditions. Actual
performance may be affected by obstacles such as trucks, mountains, trees, or power lines
SPECTRUM has an integrated antenna within the control unit, and its positioning on the
helmet can influence the range. The device should be placed in line with the riding direction.
Yes, you can use your SPECTRUM in all weather conditions. The keypad is fully waterproof,
so you do not have to worry about rain during your rides.
The charging time is approximately three hours
The battery lasts up to 20 hours of use.
First, check if you have installed the latest update. Refer to these FAQs and the Quick Guide
for potential solutions. If the issue persists, contact our support team by emailing
[email protected]. We will respond as soon as possible to help resolve the issue.
The new ECE 22-06 regulation states that every helmet component, including visors and
intercoms, must be approved according to the new standards. SPECTRUM has been certified
along with specific LS2 helmets and complies with the ECE 22-06 regulation
For a list of compatible helmets, refer to the first FAQ.
Manuals, Quick Guides and Software
Here you will find the manuals and software to configure and use your device
Packaging Disposal
Here you will find the instructions for correctly disposing of the packaging of your device
- Packaging
- PAP 20: paper
- Inner boxes/dividers
- PAP 21: paper
- Internal envelopes
- LDPE 4: plastic
- protective film
- NYLON 07c: plastic
- Box Hanger
- LDPE 4: plastic
- sponge
- Mixed: unsorted
- Cable Tie
- Mixed: unsorted
- Adhesive residue
- Mixed: unsorted
